SPARKTIDE SF-X5 5 Metre Waterproof Spark Machine

Specification

• Cold Spark Technology
• 3 Controllable variables: Height, Density and Duration.
• Ip Rate: IP55
• TFT LCD Screen

AC Power

• Input Voltage & Frequency: 240V 50HZ
• Power Consumption: 700W
• Power Input Connector: SEETRONIC

• Power Output Connector: SEETRONIC
• DMX Signal Interface: 3PIN and 5 PIN

Heating

• Heat Up Time < 5 Minutes

Hopper

• Powder tank Capacity: 300g
• Removable Hopper

Technical Parameters

• Linear Adjustable Density: 30 - 100%
• Adjustable height: 1.5 - 5m
• Height Level: 1-10 Level
• Powder Consumption (100% Output) 20 - 25g per minute
• Maximum Single Continuous Duration: 30 seconds

Control

• Control Protocol: DMX-512
• RDM
• CAN
• SMPTE: Touch Screen Console Support

Accessory

• Power Plug: SEETRONIC (1.6 Metres)
• Remote Controller: (Optional)
• DMX Cable: 3 Metres
• Power Cable: 3 Metres
• Safety Ring
• Safety Rope
• Bottom Mounting Screw

Certification

• CE
• ROHS

Weight

• Net Weight: 14.6 Kg
• Gross Weight: 17 Kg

Dimensions

• Machine Dimension: 290 x 270 x 265 mm
• Packing Dimension: 330 x 310 x 325 mm

Granule

• Spark Fabrica Granule: 200 Grams or 50 Grams
• For more information please see the Granules Safety Data Sheet.

Manual

• User Manual for Spark Tide SF-X5

Roadcase: Optional

• SPARKTIDECASE - Case for Spark Tide. Holds 2 Units.

For more information, please visit the manufacturer's website.

Warranty: 1 Year

This product contains consumables, these products are covered by DOA warranty.
