SPARKTIDE SF-X5 5 Metre Waterproof Spark Machine

SPARKTIDE SF-X5 5 Metre Waterproof Spark Machine

Regular price $3,890.00
Regular price Sale price $3,890.00
Sale Contact for Availability

Specification

  • Cold Spark Technology
  • 3 Controllable variables: Height, Density and Duration.
  • Ip Rate: IP55
  • TFT LCD Screen

AC Power

  • Input Voltage & Frequency: 240V 50HZ
  • Power Consumption: 700W
  • Power Input Connector: SEETRONIC
  • Power Output Connector: SEETRONIC
  • DMX Signal Interface: 3PIN and 5 PIN

Heating

  • Heat Up Time < 5 Minutes

Hopper

  • Powder tank Capacity: 300g
  • Removable Hopper

Technical Parameters

  • Linear Adjustable Density: 30 - 100%
  • Adjustable height: 1.5 - 5m
  • Height Level: 1-10 Level
  • Powder Consumption (100% Output) 20 - 25g per minute
  • Maximum Single Continuous Duration: 30 seconds

Control

  • Control Protocol: DMX-512
  • RDM
  • CAN
  • SMPTE: Touch Screen Console Support

Accessory

  • Power Plug: SEETRONIC (1.6 Metres)
  • Remote Controller: (Optional)
  • DMX Cable: 3 Metres
  • Power Cable: 3 Metres
  • Safety Ring
  • Safety Rope
  • Bottom Mounting Screw

    Certification

    • CE
    • ROHS

    Weight

    • Net Weight: 14.6 Kg
    • Gross Weight: 17 Kg

    Dimensions

    • Machine Dimension: 290 x 270 x 265 mm
    • Packing Dimension: 330 x 310 x 325 mm

    Granule

    Manual

    Roadcase: Optional

    For more information, please visit the manufacturer's website.

    Warranty: 1 Year

    This product contains consumables, these products are covered by DOA warranty.
