SPARKTITAN SF-X8 10 Metre Water Proof Spark Machine

Spark Specification

• IP55 (waterproof design)
• Spark effects up to 10 metres

AC Power

• Input Voltage & Rate: 240 V 50 HZ
• Power Consumption: 1700W
• Power Input Connector: SEETRONIC

• Power Output Connector: SEETRONIC
• DMX Signal Interface: 3 PIN / 5 PIN double DMX interface

Heating

• Heat Up Time: < 5 Minutes

Hopper

• Powder Tank Capacity: 450 grams

Technical Parameters

• Linear Adjustable Density: 30-100%
• Adjustable Height: 3.5 - 10 metres
• Height Level: 1 - 10 Level
• Powder Consumption (100% Output) 40 - 50g per minute
• Maximum Single Continuous Duration: 30 seconds

Control

• Control Protocol: DMX512
• RDM

• CAN

• SMPTE: Touch Screen console support

Accessory

• Power Plug: SEETRONIC (1.6 Metre)
• DMX Cable: 3M
• Power Cable: 3M
• Safety Ring
• Safety Rope
• Bottom Mounting Screw

Certification

• CE
• ROHS

Weight

• Net Weight: 24Kg
• Gross Weight: 26Kg

Dimensions

• Machine Dimension: 400 x 335 x 313 mm
• Packing Dimension: 400 x 315 x 313 mm

Granule

• Spark Fabrica Granule - 200 grams or 50 grams
• For more information please see the Granules Safety Data Sheet.

Manual

• User Manual for Spark Titan SF-X8

For more information, please visit the manufacturer's website.

Warranty: 1 Year

This product contains consumables, these products are covered by DOA warranty.
